electro hydraulic thruster

Specification：ED

Description：ED series electro-hydraulic thruster is a kind of drive control system, which is very compact in structure and integrated electrical motor, centrifugal pump and oil cylinder. It is extensively used as drive mechanism of various drum and disc brakes and as drive control of various industrial valves, penstock, directional pendulum and steering(<90℃) mechanism and clamping devices.

Prodcut Content：

Komay Ed Series electro-hydraulic thrusters

Standards compliant

ED series comply with DIN 15430 standard.

Main design Features

The casing is made by casting aluminum alloy, light and good-look.
Electrical motor is of non-under-oil structure. B grade or F grade insulation(according to customer’s requirements), durable and good heat resistance.
Cover of junction box is tightly sealed. Cable stuffing box is adopted for inlet wire, which is firm and reliable. Electrical protection of casing reaches IP55 grade.
The surface of motor axle and pusher is handled specially to make the sealing parts much durable.
Balancing air housing is set at one side of oil cylinder casing. which can make the thruster to be installed at any direction within range 0-180°and enlarge the using range.
All sealing parts and bearing for Ed series are all world famous products. The sealing is reliable and durable. Fastening parts of Ed series are made of stainless steel, good-look and durable.
